Supplier
ALFYMA
Horizontal Diverter (Pusher)
Floor-standing pusher that ejects baggage at 90 degrees off a conveyor line.
Pricing
Request a quote for current pricing, lead time and delivery to your airport.The ALFYMA pusher is a horizontal diverter mounted in tandem with a conveyor belt to quickly eject baggage at 90 degrees, typically on the HF/waste line. A connecting-rod system gives the pusher pallet a combined translation-and-rotation motion; the pallet is a metal plate coated with a low-friction, shock-damping elastomer, with adjustable pneumatic or hydraulic return damping.
Specs at a glance
Technical specifications.
| Ground-standing chassis independent of the conveyor, height-adjustable and isolated by elastic studs | |
| Metal pusher pallet coated with low-friction, damping elastomeric material | |
| Adjustable pneumatic or hydraulic return-stroke damping; position-control sensor set | |
| Pallet rest surface aligns with conveyor edges; minimal pallet-to-edge clearance | |
| Floor fixing by self-drilling or chemical anchors; soundproofed and ventilated motor crankcase | |
| Cycle time and flow rate matched to the line's required baggage flow |
Best for
Use cases.
- ›Diverting baggage off the main line on HF / waste / reject lines
- ›90-degree baggage ejection onto a perpendicular conveyor
- ›High-speed sortation points within a baggage-handling system
