Supplier
CDS-AGL Grouts
Runway Lighting & Airfield Electrical
cds-AGL SlotRestore rigid
Rigid epoxy grout for filling AGL cable slots in concrete pavements
Specs verified against manufacturer documentation
Specific weight (mixed)
1.86 g/cm3
Mixing ratio A:B = 91.5
8.5
Solids content
99 +/-1 % by weight
Compression strength
>=70 MPa
Pricing
Request a quote for current pricing, lead time and delivery to your airport.A plasticiser-free, low-viscosity two-component epoxy resin for filling saw-cut AGL cable slots and ducts in concrete airside pavements (not for casting expansion joints). It cures to a rigid, high-strength fill matched to concrete; at temperatures above 25 C up to 25 % fire-dried quartz sand (0.1-0.3 mm) may be added. Concrete edges are primed with cds-Primer MB and the slot filled within about 2 hours.
From the manufacturer’s documentation
Technical specifications.
| Specific weight (mixed) | 1.86 g/cm3 |
| Mixing ratio A:B = 91.5 | 8.5 |
| Solids content | 99 +/-1 % by weight |
| Compression strength | >=70 MPa |
| Tensile bending strength | >=30 MPa |
| Bonding strength to concrete | >=1.5 MPa |
| Application temperature | min +15 C (S) / +10 C (FH), max +35 C (S) / +25 C (FH) |
| Delivery unit | 10 kg incl. hardener; colour grey |
Best for
Use cases.
- ›Filling and restoring saw-cut AGL cable slots in concrete runways
- ›Rigid cable-duct sealing matched to concrete pavement stiffness
- ›Protecting AGL primary cables in rigid airside pavements
