TSU3000 Toilet Service Unit
Vacuum-evacuation aircraft toilet/lavatory service truck.
Pricing
Request a quote for current pricing, lead time and delivery to your airport.The Mallaghan TSU3000 toilet service unit is designed to service the toilet tank of all aircraft types using the vacuum evacuation principle. It uses a 304-grade stainless steel waste tank mounted in tandem with a flush tank, attached to the vehicle chassis on independent flexible rubber mounts, with a waste vacuum and tank-rinsing system. Options such as a rear lift basket and various tank sizes allow it to be configured to suit different operations.
Specs at a glance
Technical specifications.
| Capacity 3000 litre (EU/UK/ROW) | 2000 litre effluent / 1000 litre flushing water |
| Americas | 700 gal — 400 gal effluent / 300 gal flushing water |
| 304-grade stainless steel waste tank in tandem with flush tank | |
| Waste vacuum system, tank-rinsing system, resettable flow meter, low-level gauges | |
| 25 mm / 1 in water hose and 100 mm / 4 in waste hose on retractable reels; 4 in dump valve | |
| Standard commercial chassis (MAN, Mercedes, Isuzu etc.); services driven via power take-off | |
| Options | winterisation, hydraulic rear platform, disinfectant dosing system, 4500 litre model (excl. Americas) |
Best for
Use cases.
- ›Emptying and flushing aircraft lavatory waste tanks during turnaround
- ›Lavatory servicing across narrow- and wide-body aircraft types
- ›Toilet-servicing fleets for airports and ground handlers
