ADB SAFEGATE RELIANCE Individual Light Control (IL)
Single-fixture control and health monitoring over the series loop.
RELIANCE IL is ADB SAFEGATE's flagship individual light control and monitoring system. A modem inside each fixture's isolation transformer rides the 6.6 A series loop, giving the tower a per-fixture addressable view of on/off state, intensity and lamp health. It supports CAT I, II and III stop-bars and routing-clearance lighting and is the engine behind A-SMGCS Level 3 routing. Integrates with the ACE airfield lighting control system.
ADB SAFEGATE RELIANCE Individual Light Control (IL)
runway · lighting · airfield · electrical
AVS·CAT
Product at a glance
- Category
- runway lighting airfield electrical
- Launched
- 2018
- Price tier
- enterprise
- GCC sites
- 6
- Status
- ● Current model
Technical specifications
Key specs
| Loop current | 6.6 A series |
| Addressable fixtures per loop | up to 200 |
| Protocol | Power-line carrier over series cable |
| Latency (command to action) | < 1 s |
| Lamp-out reporting | Per fixture, real-time |
| Standard | Supports ICAO Annex 14 CAT III stop-bars |
| Control interface | ACE HMI, A-SMGCS Level 3 |
| Voltage isolation | Full galvanic via L-830 |
Compatibility
Works with
- Works with any 6.6 A series CCR
- Retrofits onto existing L-830/L-831 isolation transformers
- Integrates with ADB ACE tower and A-SMGCS suite
- Open-protocol tie-ins to Honeywell and ATG ALCMS via OPC-UA
Certifications
Approvals
ICAO Annex 14
FAA AC 150/5345-56
EASA CS-ADR-DSN
CE
Best for
Typical use cases
Use case 1
CAT III stop-bar control at a 24/7 Gulf hub.
Use case 2
Routing-clearance lighting during A-SMGCS Level 3 rollout.
Use case 3
Predictive lamp-replacement to cut runway closures.
