ADB SAFEGATE RELIANCE / AXON LED Stop-Bar (FAA L-852S(L)) — CAT II/III low-vis ops
FAA L-852S(L) in-pavement red LED stop-bar — 8" and 12" inset, low-protrusion, individual-light controllable.
ADB SAFEGATE's LED stop-bar product line is a core element of CAT II/III low-visibility surface operations. The current AXON LED Stop-Bar is the latest-generation in-pavement fixture, with improved optics and reinforced mechanical design paired with smart electronics for multiple control and monitoring options. The earlier RELIANCE Stop-Bar (now discontinued in favour of AXON, but still widely deployed and supported) is a low-protrusion 8" or 12" unidirectional red LED inset light. Both meet FAA AC 150/5345-46 L-852S(L) and ICAO Annex 14 chromaticity for stop-bar applications, and support style III low-protrusion mounting on standard L-868 12" base cans. Both can be equipped with the IQ built-in ILCMS remote — a unique building block for the intelligent airfield — enabling per-fixture remote control via CORTEX ALCMS for SMGCS routing-clearance enforcement. The complementary ISTB-L combined Stop-Bar + Runway Entrance Light (REL) variant supports drop-in installation on existing series circuits with no modifications.
Key specs
| FAA conformance | L-852S(L) — Stop-Bar / L-852GS(L) — Runway Guard + Stop-Bar combined |
| Current generation | AXON LED Stop-Bar (improved optics, reinforced mechanical) |
| Predecessor (still supported) | RELIANCE LED Stop-Bar 8" / 12" (Style III low-protrusion) |
| Combined REL variant | ISTB-L — Stop-Bar + Runway Entrance Light, drop-in on series loop |
| Colour / direction | Red, unidirectional |
| ICAO compliance | Annex 14 Vol I — CAT II / III chromaticity |
| Mounting | FAA L-868 B/D 12" base can |
| Individual-light control | Optional IQ ILCMS remote (built-in) |
| Series-loop drive | 6.6 A — 5-step ICAO dimming |
