Supplier
Heald Ltd
Matador
Patent-protected shallow-mount sliding bollard system, crash-tested to PAS 68 and IWA 14.
Pricing
Request a quote for current pricing, lead time and delivery to your airport.The Matador is Heald's multi-award-winning shallow-mounted HVM sliding bollard system that slides apart to create a secure vehicle aperture while keeping pedestrians safe. It is deployed at airports including Avinor Oslo Airport and is available in electromechanical or manual operation with surface-mount, recessed or architectural-paving installation options. Crash testing achieved zero penetration.
Specs at a glance
Technical specifications.
| HT2 | IWA 14-1:2013 V/7200[N2A]/64/90:0.1 (7.2T @ 40mph) and PAS 68:2013 V/7500(N2)/64/90:0.7/0.0 (7.5T @ 40mph) |
| HT3 | IWA 14-1:2013 V/7200[N3C]/64/90:1.3 (7.2T @ 40mph) and V/7200[N2A]/80/90:3.2 (7.2T @ 50mph); CPNI VADS rated |
| Bollard height 1030mm (1050mm with covers); core diameter 220mm HT2 / 273mm HT3 | |
| Foundation depth from 150mm reinforced concrete (surface mounted) | |
| Operating speed 6 sec (3 sec EFO) for 3-4 bollards; max opening up to 7092mm (HT3 6-bollard) | |
| Power supply (EM) | single phase 13A |
| Hot dip galvanised steel base, stainless steel covers available | |
Best for
Use cases.
- ›Airport and aerospace perimeter security
- ›High-profile town centres with shallow underground infrastructure
- ›Pedestrianised areas requiring sporadic road closure
- ›Building entrances and prestigious properties
